The Versa Certified SD-WAN Associate (VNX100)

URL-based Zero-Touch Provisioning (ZTP) is an approach where the URL of a Versa Operating System activation website is emailed to the installer at the customer site. The installer then connects a laptop to the Wi-Fi or LAN port of the Versa branch device, clicks on the URL, and completes the provisioning process. This method does not require a console connection and is one of the methods provided by Versa to provision and configure new VOS devices, making the process convenient and straightforward. ​

The diagram in the exhibit illustrates a hub and spoke topology where the spokes connect through a central hub. This is evident from the dashed lines that show the data flow between the spokes is mediated by the hub (Hub1). In this topology, while the spokes may have direct connections, the data flows between them pass through the hub. This kind of topology is commonly used in SD-WAN deployments to simplify routing and policy enforcement, which are managed centrally at the hub, as opposed to setting up direct paths between all spoke sites, which would be indicative of a full mesh or spoke-to-spoke direct topology.

Top of Form

An SD-WAN Forwarding Profile is a set of rules that determine how outgoing traffic should be handled within the SD-WAN network. It particularly defines which WAN links should be selected for forwarding the traffic based on certain criteria such as link performance, priority, and SLA compliance. The Forwarding Profile ensures that traffic is directed over the most appropriate link, which may involve decisions based on the link's performance metrics like latency, jitter, or packet loss, ensuring efficient and optimal use of the WAN infrastructure​​.

In a Versa Analytics cluster, the node personalities include Search and Analytics. These personalities reflect the different roles each node in the cluster plays. The Search nodes are responsible for ingesting and indexing data, enabling fast and efficient search operations, while the Analytics nodes are responsible for processing and analyzing data, providing insights and reports. This separation of duties is key to the operation of a Versa Analytics cluster, ensuring optimal performance and reliability of the analytics platform.

In a spoke-to-hub-only topology, the only prefixes advertised by default are the hub routes, and the spoke routes are not re-advertised by the hub branch. This topology is used when spokes do not have to communicate with each other, and a classic example is a network of ATM cash machines where devices communicate exclusively with resources in the customer data center. The spoke devices, in this case, can send traffic only to networks behind the hub and not to other spokes directly or through the controller.

To implement a third-party application server as a virtual machine on a Versa CPE, the Service Chain Template should be used. This is because the Versa uCPE solution supports service chaining capabilities which are necessary for steering traffic to and from third-party virtual network functions (VNFs) to Versa Operating System (VOS) instances. The Versa uCPE solution can manage the lifecycle of third-party VNFs, including the ability to bring up an out-of-band management interface for each VM, connecting it to the Versa secure management channel, and routing management and control plane traffic accordingly​​.

When a speed test fails, it could be due to the speed test module not being activated or the speed test server not being enabled at the remote site. If the speed test module has not been activated, the required functionality to conduct the test will not be operational. Similarly, if the remote site does not have the speed test server enabled, it won't respond to speed test requests. Issues with the SLA path status or client configuration might be relevant to the performance and reachability but are not cited as direct reasons for a speed test failure within the documentation provided.

The default load balancing algorithm set in an SD-WAN Forwarding Profile is Weighted Round Robin (WRR). This algorithm assigns weights to each path based on the available bandwidth on the access circuit. WRR is recommended when paths with equal priorities are provisioned with different bandwidths, ensuring that traffic is distributed proportionally to the bandwidth of each path, which optimizes the utilization of network resources and maintains load balancing across the WAN circuits​​.

Versa SD-WAN headend components, which include the Versa Controller, Versa Director, and Versa Analytics, offer flexible deployment options. They can be deployed on bare metal servers, as virtual machines, or as a hybrid of both, depending on the scalability needs and the available infrastructure at the data center or cloud environment. This flexibility ensures that Versa SD-WAN can adapt to a variety of enterprise environments and deployment scenarios. ​
